What are the key safety standards to consider when installing narrow & high-bay longspan warehouse racking systems?

Installing narrow and high-bay longspan warehouse racking systems safely requires a competent design, verified load information, suitable floor and anchorage arrangements, controlled installation, impact protection and documented inspection procedures. The installation should comply with the relevant British and European standards, the manufacturer’s instructions and UK workplace health and safety requirements before it is put into service.

Design and specification standards

The system should be designed for the building, loads and handling equipment that will actually be used. This includes assessing the bay dimensions, beam spans, upright configuration, pallet or product type, loading method, forklift operating areas and available clearances. A competent designer should establish the intended duty and confirm that the proposed components are suitable for the required loads.

Relevant standards commonly include:

• BS EN 15629, which covers the specification of storage equipment;
• BS EN 15620, which addresses tolerances, deformations and clearances;
• BS EN 15512, which covers the structural design of adjustable pallet storage systems; and
• BS EN 15635, which provides guidance on the use and maintenance of steel static storage systems.

The precise standard requirements depend on the system configuration and application. A supplier or installer should be able to explain the design basis and provide suitable technical information rather than relying on a generic layout.

Load capacity and configuration

Every beam level and upright frame must be suitable for its intended load. Load calculations should consider the uniformly distributed load, the number of levels, the position of loads, pallet dimensions, point loading, accidental impact and any future changes to the layout. Longspan systems are often used for hand-loaded goods, but their capacity can vary considerably according to the beam, decking and frame arrangement.

Loads must not be increased, redistributed or stored in a different format without checking the design. Adding levels, changing beam positions, replacing components or using heavier goods can affect the structural capacity. The safe working load should be displayed clearly on a durable load notice at the relevant storage area, with any limitations explained to the people using the system.

Floor condition and anchorage

The floor must be capable of supporting the imposed loads and remaining sufficiently level for the planned installation. High-bay systems are particularly sensitive to alignment, plumb and floor tolerances because small deviations can affect stability and clearance at height. The floor should be checked before installation, including its condition, thickness and suitability for the specified anchors.

Uprights should be anchored in accordance with the design and manufacturer’s instructions. Anchors must be compatible with the floor construction and installed correctly, with damaged or incorrectly positioned fixings rectified before the system is loaded. Where the building structure, services or floor cannot support the proposed arrangement, the design must be revised rather than relying on improvised reinforcement.

Stability, clearances and protection

The completed warehouse racking system must remain stable under normal loading and foreseeable operational conditions. This includes providing the required bracing, frame connections, beam locks and other structural components. Components should not be cut, drilled, welded or substituted without approval from the designer or manufacturer.

Clearances should be sufficient for the loads, handling equipment and operating conditions. Narrow aisles require particularly careful coordination between the warehouse racking layout and the trucks or other equipment used within them. The design should allow safe manoeuvring, prevent loads from striking adjacent bays and maintain access to emergency routes, doors, fire equipment and building services.

Protection may be required at exposed ends, corners, uprights and other areas vulnerable to impact. The type and position of protection should reflect the vehicles, traffic routes and likely impact points. Protectors are not a substitute for good traffic management, and damaged protection should be repaired or replaced promptly.

Safe installation practices

Installation should be planned and supervised by people with appropriate knowledge and experience of the system. The work plan should address delivery, component storage, lifting, temporary stability, exclusion zones, work at height, traffic segregation and the sequence for securing frames and beams.

Installers should use suitable access equipment and follow the requirements of the Work at Height Regulations where work is carried out above ground level. Components should not be left in an unstable condition during breaks or at the end of a shift. The installation area should be kept clear of unauthorised personnel and warehouse vehicles until the system has been secured and released for use.

Work equipment used during installation should be suitable, inspected and operated by trained personnel. Where lifting equipment or forklift trucks are involved, the relevant requirements of the Provision and Use of Work Equipment Regulations and the Lifting Operations and Lifting Equipment Regulations should be considered.

Access, loading and operational controls

Users need clear instructions for loading and unloading. Loads should be positioned evenly, kept within the designated bay and prevented from projecting into aisles or striking beams and uprights. Damaged pallets, unstable goods and loads that exceed the stated capacity should not be stored.

Pedestrian and vehicle routes should be defined, with suitable separation where the risk assessment identifies a need. High-level work should only be carried out using a planned and suitable access method; people should not climb the warehouse racking or use pallets as makeshift working platforms. Emergency arrangements should cover falling goods, impact damage, blocked routes and evacuation.

Inspection, handover and records

The installation should be checked by a competent person before use. This pre-use inspection should confirm that the warehouse racking matches the approved design, is correctly assembled and anchored, has the required bracing and beam locks, and is free from visible damage or unacceptable deformation.

A proper handover should include the layout or design information, load notices, manufacturer’s instructions, inspection arrangements and any restrictions on use. Records should identify the system, inspection findings, remedial actions and the person responsible for closing out defects.

Once operational, users should carry out routine visual checks and report damage immediately. A technically competent person should complete a systematic inspection at intervals appropriate to the risk and, in line with BS EN 15635 guidance, at least annually. More frequent inspections may be necessary where vehicle movements are intensive, damage has occurred or the working environment changes.

Any component that is bent, cracked, displaced, missing or otherwise damaged should be assessed promptly. Affected bays may need to be unloaded and isolated until a competent person confirms that they are safe, or repairs are completed using approved components and methods. Regular inspection and controlled maintenance help preserve the designed capacity and prevent minor defects from developing into structural failures.

In practice, the safest installation is one supported by a documented design, competent fitting, accurate load information, effective impact controls and an inspection regime that continues after handover. These measures provide evidence that the system has been installed and managed with the risks of narrow aisles, high-level storage and day-to-day warehouse operations properly considered.
